Revit Roof Plan Lower Level Light Fixtures Showing Up

Now my problem is i drew the ground floor plan in level 1.

Revit roof plan lower level light fixtures showing up. If i then go to my level 1 plan and select underlay option my walls show up however if i change my wall extents from base level 2 top level 3 to top level 3 0 1 i will no longer see the underlay this has no relation to the view depth settings as i ve tried to get both my working file to fail in this way and a test. So i change the underlay parameter you find this is the properties palette to the level where your roof or roof light canopy etc resides. When people copy a view and then rename it renaming a copy of level 1 to level 2 does not create view based on level 2 it is locked into the original level level 1 in this case. How do i stop it from showing and interfering.

I drew this in revit architecture 2015. And now i need to set it s underlay to show the roof element. First of all i need to open the ground floor plan. That sounds like a nasty little endless loop.

With few exceptions all visibility settings in revit occur at the view level. When i go to level 2 the floor plan is visible and interferes when i try to draw in level 2. Ok im almost a total noob in this i started using revit today and finished drawing a ground floor plan for a house. Open the plan view of the level in which you want to see the roof line.

If you are in the level 3 plan view then the base constraint will be set to level 3. If you are in a level 1 view and set the top offset to level 2 the next. And so on to roof. The top offset will default to the last used value e g.

I have revit 2016 as well. In the view properties expand the underlay drop down and select the level on which the roof was created to display as an underlay. Select the linework tool in the view panel on the home ribbon. A new view must be created as a copy of a view associated with the correct level or by using the view ribbon plan view choosing the correct plan view type and level.

So one of the easiest things you can do to find a missing element is open or create another view. In plan view click view menu view properties. Just for future reference when placing walls revit will default the base constraint to the level of the view you are in. We need to show elements typically only seen in the reflected ceiling view to show up in our floor plan view br br this little trick will show you how to use the magic model line to trick revit to show in a floor plan view items in the ceiling br br enjoy br rick kremer br applied software.

This makes the roof line visible in the plan view but the lines appear as solid lines.
